KAKA INDUSTRIAL W-10012A Heavy Duty Pan & Box Brake
100" Working Width | 12 Gauge Mild Steel Capacity | 0°–135° Bend Range
🟦 EXTRA-WIDE • HEAVY-DUTY • SEGMENTED FINGERS • PRECISION FORMING
The KAKA INDUSTRIAL W-10012A Pan & Box Brake is a heavy-duty industrial sheet metal folding machine designed for large-format fabrication work. With an impressive 100-inch bending width and capacity up to 12 gauge mild steel, it is built for forming long panels, large boxes, pans, enclosures, ductwork, brackets, and custom sheet metal components.
Its 15 removable finger segments, ranging from 2.5" to 12", provide excellent flexibility for complex box and pan fabrication. The segmented fingers can be rearranged to accommodate different workpiece widths and shapes, making the W-10012A suitable for both repetitive production and custom fabrication.
A rugged welded steel frame provides the rigidity required for accurate bending across the full working width, while the heavy-duty hold-down clamping system securely positions the material during forming. With a maximum bending angle of 135°, the W-10012A is ideal for professional fabrication shops and industrial manufacturing environments that require both high capacity and versatility.
⚙️ KEY FEATURES
🔹 100" Extra-Wide Bending Capacity
Handles sheet metal up to 100 inches wide, making it ideal for large panels, enclosures, ductwork, and industrial fabrication.
🔹 12 Gauge Mild Steel Capacity
Designed to form mild steel up to 12 gauge for demanding heavy-duty sheet metal applications.
🔹 0°–135° Bending Range
Provides a wide bending range for boxes, pans, brackets, channels, and custom formed parts.
🔹 15 Removable Finger Segments
Includes 15 removable finger segments in multiple widths for flexible box and pan fabrication: 1 × 2-1/2", 1 × 3", 1 × 3-1/2", 1 × 4", 3 × 5", 4 × 6", and 4 × 12"
The segmented fingers can be removed and repositioned to accommodate different workpiece widths, box sizes, and custom forming applications.
🔹 Repositionable Finger Design
Finger segments can be removed and rearranged to accommodate different workpiece widths and complex forming applications.
🔹 Heavy-Duty Hold-Down Clamping System
Strong clamping levers securely hold sheet metal in position for accurate and consistent bends.
🔹 Welded Steel Construction
Heavy-duty welded frame provides excellent rigidity and minimizes flex during bending.
🔹 Designed for Large-Format Fabrication
Ideal for fabrication shops that regularly work with oversized panels and long sheet metal components.
🔹 Manual Heavy-Duty Operation
Reliable mechanical design requires no electrical or hydraulic power for standard bending operations.
📐 SPECIFICATIONS
| Specification | Details |
|---|---|
| Item No. | 173129 |
| Model | W-10012A |
| Maximum Bending Width | 100" |
| Mild Steel Capacity | 12 Gauge |
| Maximum Bending Angle | 0°–135° |
| Finger Segments | 15 Removable Segments |
| Finger Size Range | 3"–20" |
| Construction | Heavy-Duty Welded Steel |
| Packing Size | 118" × 30" × 40" |
| Net Weight | 2,695 lbs |
| Gross Weight | 3,014 lbs |
🧰 IDEAL APPLICATIONS
🏭 Industrial Sheet Metal Fabrication
🏠 Large HVAC & Ductwork
📦 Large Box & Pan Fabrication
⚡ Electrical Enclosures & Cabinets
🔩 Brackets, Channels & Fixtures
🏗 Commercial Metal Fabrication
🛠 Maintenance & Manufacturing Facilities
📐 Custom Large-Format Sheet Metal Projects
📦 WHY CHOOSE THE W-10012A?
✔ 100" extra-wide working capacity for large-format fabrication
✔ Handles up to 12 gauge mild steel
✔ 15 removable finger segments for flexible box and pan forming
✔ Finger widths from 2.5" to 12" for different workpiece configurations
✔ 0°–135° bend range for versatile forming applications
✔ Heavy-duty welded steel structure for improved rigidity
✔ Strong hold-down clamping system for secure material positioning
✔ Designed for professional fabrication shops and industrial production
