- Heavy-duty construction with hardened and ground rolls
- Horizontal & vertical working position
- Foot control with emergency stop
- Open-face design for rolling full circles
- Includes various segment rolls for flat bar, angle iron, and square tubing
RBM-40HV and RBM-50HV can bend 1-1/4" square tubing at Max.
Notice:
Carefully check whether the safety device is in good condition before use
Don't put hands and feet on the rollers and transmission parts during the operation
Disconnect the power supply after the operation is completed
Specification:
|
Item No. |
191011 |
||
|
Model |
RBM-50HV |
||
|
Dia. Of roller |
1.97” |
φ50 mm |
|
|
Power |
2.2kw/3HP |
||
|
Spindle speed |
@60Hz 10.8 R/min |
@50Hz 9 R/min |
|
|
Packing Size |
39”x32”x61” |
100x82x155 cm |
|
|
N.W./G.W. |
1012/1182 lbs |
460/537 kg |
|
|
Capacity |
Size(mm) |
Min Dia.(mm) |
|
 |
60x10 40x10 |
500 650 |
|
 |
100x15 60x10 |
920 1150 |
|
 |
35x35 20x20 |
600 780 |
|
 |
60x7 50x5 |
750 700 |
|
 |
60x7 50x5 |
750 700 |
|
 |
80x45x6 65x40x5 |
600 550 |
|
 |
80x45x6 65x40x5 |
650 550 |
|
 |
60x5 50x5 |
500 500 |
|
 |
60x5 50x5 |
700 700 |
|
 |
￠35 ￠30 |
600 650 |
|
 |
60x60x3 40x40x3 |
600 500 |
|
|
70x50x3 |
1200 |
|
|
50x40x3 |
800 |
||
All the above processing capacities can be finished by one set of standard combination roller
Special roller for round tube:
|
Profile |
Size(mm) |
Min Dia.(mm) |
 |
30x2 35x2 40x2 45x3 50x2 55x2 60x2 65x2 70x2 |
600 |
We can design the rollers for you as per your special requirements. We can also make the rollers in various materials such as nylon
